Model |
BR-RVC07-TC-LED |
|
|
Camera |
Sensor |
1/3 CCD |
|
|
TV System |
PAL/NTSC |
|
|
Min IIIumination |
0.1Lux@(F1.2,AGC ON);0Lux With IR |
|
|
Electronic Shutter |
Auto:PAL 1/50s(NTSC 1/60s)~1/100,000s |
|
|
Focus |
2.8mm |
|
|
Lens Interface |
M12 |
|
|
F.O.V |
120° (D)、95°(H)、70°(V) |
|
|
Backlight Compensation |
Auto |
|
|
Resolution |
700TVL |
|
|
Signal to Noise ratio |
Better than 48dB |
|
|
Ir LED |
10 |
|
|
LED NUM |
3*2835LED |
|
Interface |
Video Output |
1Vp-p Composite Output(75Ω) |
|
|
Audio Input |
N/A |
|
|
Audio Output |
N/A |
|
|
LED Power Interface |
2PIN(12V) |
|
General |
Material |
Metal& Plastic |
|
|
Operating Temperature |
-30℃~70℃ |
|
|
Power Supply |
DC12V±10%(From Reversing Monitor) |
|
|
Power |
|
|
|
Waterproof |
IP69 |
|
|
External Dimensions |
|
|
|
Weight Approx |
|
