Model

BR-RVC06-SW

Camera

Sensor

1/2.9 CMOS

TV System

NTSC/PAL

Camera Ir LED

None

Min IIIumination

0.1Lux@(F1.2,AGC ON);

Electronic Shutter

Auto:PAL 1/50s(NTSC 1/60s)~1/100,000s

Focus

1.78mm

Lens Interface

M12

F.O.V

180° (D)、160°（H）、93°（V）

Backlight Compensation

Auto

Resolution

1920*1080(AHD 1080P)

Signal to Noise ratio

Better than 48dB

Interface

Connect

4 PinAviation Female Interface

Video Output

1Vp-p Composite Output(75Ω)

Audio Input

NONE

Audio Output

NONE

General

Material

Metal

Operating Temperature

-30℃~70℃

Usage

For passenger vehicles

Operating Voltage

DC 9-36V±10%(or From Reversing Monitor DC12V)

Power

Waterproof

IP69K

External Dimensions

38.5*36.4*35.5mm(L*W*H)

Weight Approx
